Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 69

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 69
thethroat of a doublecone. Designedfor the most eco-nomical combus-tion of oil. 64 GENERATION OF POWER, STEAM. 115. FUEL OIL BURNER. An air burner. Brown type.The air issues in an annular converging cone d, meeting the small jets of oil from the cen-tral apertures. Thecentral tube D alsoejects…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
