Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 69

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 69
ughs, a, a, a, containing the liquid fuel, the discharge of which is regulatedby small basins, r, r1, r, that communicate withthe troughs at b, b. Through the basins passdischarge pipes, T, T, T. open at each ex-tremity. All the parts of the grate are of ironcast in a piece, and comprising no… … GENERATION OF POWER, STEAM. 65
