Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 72

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 72
tby gravity or pressure.The weight of the wateralternately filling thechambers, carries themdown and opens a steamport in the axial valve tothe boiler pressure, whenthe water flows into the boiler by gravity. At the same time theupper chamber is being filled by the condensation of its steam. It… … 6S GENERATION OF POWER, STEAM.

Mechanical movements
