y gearsto the cone, any slight variation of the cone affects the crown gear.The driving gear C and the crowm gear impart their speed to the bob-bin gear. Its speed will be in excess of the spindle gear S. As an ilhistration of its influence, we will suppose the drivingshaft is making 300… … 818 WOOT>EN AND ^YORSTED SPINNING 199 there are then 310 revolutions or a reduction of thirty caused by theaction of the cones. In Fig. 126, on the shaft O, there is a small bevel pinion ]M whichgears into N which is fixed on the top of a vertical shaft, at the oppositeend of which is another…
