Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 73

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 73
air or steam from the feed tank ; C is a cock to let steam from the boiler to the tank ; D is a cock to let water from the tank to the boiler. The bot- mm torn of the tank should be ^1 above the highest water levelto be carried in the boiler. Thelowest level of the water supplymust be higher than… … GENERATION OF POWER, STEAM. 69
