Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 79

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 79
142. TYPES OF COMPOUNDENGINES. Twin compound, closeconnected tandem with high-pressurecylinders forward, cranks at 1200 onends of shaft, fly wheel in center. 143. The relative positions of thepistons are shown in the two figuresat alternate strokes. 73 74 STEAM POWER AFPLIANCES. … 144. TYPES OF COMPOUNDENGINES. Tandem compoundtypes in which the forward cylinderis high pressure with close connection f~3 to the low-pressure cylinder with onlyzg a metallic sleeve as a stuffing box. 145. In the reverse type the cylin-ders are independent and separated ashort distance with…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
