Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 76

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 76
139. TYPES OF COMPOUND ENGINES. Single cylinder or trunk engine in which the highand low pressure areas are adjusted by the size ofthe piston rod or trunk, which is inclosed by a stuffingbox. The connecting rod is jointed within the trunk. … 140. TYPES OF COMPOUNDENGINES. Cross compound withcranks at 120° on ends of shaft. Flywheel in center. In this type there isno dead center. 141. Low-pressure cylinder, showingrelative positions of piston.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
