Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 82

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 82
cylinder. The releasing gear of this type of engine is unique in thatinertia, centrifugal force, and the force of gravity are used to operatethe grab hook. STEAM POWER APPLIANCES. 77 151. COMPOUND CORLISS … ENGINE. Showing Corlissvalves on low-pressure cylin-der, direct connected wristplates, one for each cylinderto operate the steam valveswhile the exhaust valves areall connected by link rods,which are in turn directlyconnected to the eccentricrod. Valve gear of both cyl-inders have trip hooks…
