r of low-pressure piston, as the sleevein question slides into the high-pressure cylinder and both pistons canbe moved forward together and out of the cylinders. The valves are connected by a rod passing through a pipe betweenthe steam chests of the high-pressure and low-pressure cylinders.… … VALVE IN OPENING POSITION
