Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 90

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 90
176. RIDING CUT-OFFVALVE. From single eccen-tric. The main valve is movedby the direct connected valverod. The riding valve is movedby a short lever and links piv-oted to the two valves. … 177. TYPES OF SLIDEVALVES. Slide valve of theBayley engine. A flat valve ridingunder a balanced pressure plate.Pressure plate is held in place bystays against the steam chest. 178. PARSONS STEAM TURBINE. Steam is admitted at thegovernor valve and arrives at the chamber, A, at the small end of the

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
