Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 93

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 93
:-. THE STEVENSVALVE GEAR. Showingthe double toe and wipers withthe eccentric rod unhooked.Type used on the Hudson Riversteamers. First used in 1840.A standard type for marine walk-ing-beam engines. … 185. VALVE GEAR. A wrist plate journaled on a pin carriedby a standard or post on the engine frame. The wrist plate is rotated by the eccentric, the motionbeing communicated to the sev-eral valves by suitable rodswhich are connected to twohorizontal links pivoted to thewrist plate ; these links…

Mechanical movements
