Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 94

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 94
a spring. The block C carries apin, E, on the rear side, which is held incontact with a cam ring, F, having twov\N, M^^g Ajg^^^0* knock-off dies, M and N, on its inside sur-face. As the bell crank moves in thedirection of the arrow from the positionshown, the roller on the pin E strikes thecam die…

Mechanical movements
