Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 95

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 95
188. CORLISS VALVE GEAR. In thisdesign, B is the bell crank, which carries thehook H mounted on a short shaft, on theother end of which is the trip lever (not shown),which engages with the knock-off cam C, oper-ated by the governor rod. K is the drop leverwith dashpot connection. The cam lever… … 190. CORLISS VALVE GEAR. Thisdesign consists principally of a curved bellcrank. B. earning the grab hook D mountedon a short shaft having an arm at the otherend. The trip lever d rides on the knock-offcam A. the position of which is controlled bythe governor, as usual, ^hen the bell crankreaches…
