Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 96

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 96
196. REVERSING GEAR. Wolf type. E, is the eccentric; B, eccentric strap and arm ;/, a pin sliding in the link,S, which is moved to theposition S for reversing;a R, valve rod connected tothe eccentric arm at a. Theelliptic line, /, shows therange of the valve motionand swings to the vertical with… … 92 STEAM POWER APPLIANCES.

Mechanical movements
