The principles and practice of textile printing (1912)
Knecht, Edmund, 1861-1925, Fothergill, James Best · London : Charles Griffin · leaf 93
of the roller equal in width to thelength of the mill is fully engraved all round, the mill is lifted, and,together with the pressure lever, is moved laterally to its next position by meansof the travelling lever-support. The next position is, of course, that in whichthe side repeats join up… … Fi,. 32.—Diagrammatic sketch of engraving machine. In fig. 32 (which pretends to no more than to illustrate, in simple diagram-matic form, the principle of machine engraving) the disposition of the essentialparts of an engraving machine are shown. K is the roller, M the mill, B theadjustable…
Textile printing
