HANICAL DRAWING line of the cutting plane is given and the section drawnin another place. This is illustrated in Fig. 54. Inthis figure the lines A B and C D represent the linesof two cutting planes^ and the figures below the draw-ing show the shapes of the sections. It is necessaryto distinguish…
