ht, to be taken, respectively, from thefigures shown on pages 49 and 50. The problemswill be selected by the instructor. Make three views, complete with dimension linesand dimensions. If possible, leave at least 1^ be-tween the views, and locate the drawing in the rec-tangle with equal spaces at… … Plate 3 50 MECHANICAL DRAWING
