Babbit, Arthur B · New York, H. Holt and company · leaf 77
ing out the views are the same as for the singlepiece, although more care isrequired in the selection ofviews, in order to show theconstruction clearly and atthe same time to use as fewdotted lines as possible.Dotted lines on a drawingare always confusing, and inmany cases one combinationof views… … /vy. 36 ASSEMBLY DRAWINGS 67 fits into the recess cut into the other piece at B. Anassembly drawing of this same joint, using threeviews, is shown in Fig. 37. In reaUty, two views willshow the details of construction clearly. These two % rn 7. ^7 views, with the dimensions for making each part,are…
Mechanical drawing
