Babbitt, Arthur B. (Arthur Bradford), b. 1873 · New York, H. Holt and company · leaf 131
120 MECHANICAL DRAWING … ■^9. ^^2 passing through the axis. After passing this cuttingplane through the piece, and removing the front halfof the cylinder, we would have what is representedin Fig. 42. Two views of the modelshown in perspective in Fig. 41 aregiven in Fig. 43, while in Fig. 44are shown two views after the…
Mechanical drawing
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
