To draw a line through agiven point parallel to agiven line—With the givenpoint A as a center withany radius, draw arc 1, in-tersecting the given line atB. With B as a center withthe same radius, draw arc2 through A intefrsectingthe given line at C. Witha radius equal the distance 184 MECHANICAL… … PROBLEM 8 To divide a straight line intoany number of equal parts— At any angle with the givenline, A B, draw an indefiniteline A C. Lay off on thisline the required number ofequal spaces. Through thepoints thus obtained drawa series of lines parallel toa line connecting the lastpoint and the end…
