Mechanical drawing problems for high schools, normal schools and vocational schools (1918)

Berg, Edward. [from old catalog], Kronquist, Emil F. (Emil Fritjoff), b. 1882 · Peoria, Ill. : The Manual arts press · leaf 60

An illustration from Mechanical drawing problems for high schools, normal schools and vocational schools, 1918, leaf 60 — r8 MECHANICAL DRAWING PROBLEMS Specification—Plate 13.Make a complete working drawing of the Clutch Thimble. Scale I2=i. Title:— CLUTCH THIMBLE SCALE DATE NAME In a drawing of a cylindrical object of many diameters and where one of the views con-sists of many circles, it is not good practice to…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
