width. The length of the top viewis equal to the length of the front view. Its width is aboutone-fourth of its length. The height of the side view is equal tothat of the front view. Its width is about one-half of its height.4. The distances from the views to the border line above andbelow the views… … Fig 121. Lettering Plate 12 5. When the rectangles are properly located, sketch in lightlythe details of each view, proportioning them by eye. 6. Complete the views by retracing the lines. 7. With the advice and suggestions of the instructor, selectthe necessary dimensions and then draw extension…
Mechanical drawing
