Fig. 170. Medicine Cabinet Given: Fig. 170. The front and right side views.Required: To draw the front and left side half section views. Given: Fig. 171. The front and right side views.Required: To draw the front, and left side half section. Instructions : Proceed as for the mechanical drawing… … Sect/on showing consrructtonof cushion Fig. 171. Foot Ktool PREPARATORY INSTRUCTIONS FOR DRAWING PLATE 19 The following is a list of the instruments and materials neededto make tracings and reproductions of mechanical drawings: 1. Tracing cloth. 2. Tracing paper. 3. Blueprint paper. 4. Black…
Mechanical drawing
