Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 325
Fig. 362. To Bisect an Angle Instructions: With B as a center, draw an arc AC of anyradius. With A and C as centers describe arcs of equal radiusintersecting in D. BD bisects the angle ABC. . … Fig. 363. To Trisect a Eight Angle PROBLEM 4 Given: A ngr/i;^ angle AB C. Required: To trisect angle ABC. Fig. 363. GEOMETRICAL CONSTRUCTIONS 321 Instructions: First Method. With B as a center, draw anarc A C of any radius. With A and C as centers and the sameradius, draw arcs B D and B E. The…
Mechanical drawing
