4i- Fig. 22. Scale of Levels 2. In general, equal vertical distances are equal in perspectiveonly when measured on the same vertical edge. Example:AB = BK = KL. PERSPECTIVE SKETCHING 33 … 34 MECHANICAL DRAWING Horizontal Measurements. Under, Horizontal Lengths inPerspective, page 12, the general facts regarding horizontalmeasurements are given. In making horizontal measurements inperspective the following method should be used: Whenever possible, horizontal distances on an object…
