Mechanical drawing : a manual for teachers and students (1902)
Cross, Anson Kent · Boston : Ginn & Co. · leaf 106
173. … 172. Drawing B represents a cube and aHne I which is in the same plane as the rightand left vertical edges of the cube, and there-fore intersects these edges. Line 2 is in frontof the right and left vertical edges ; its intersec-tions with the faces of the cube are seen in thetop view, and may be…
Mechanical drawing
