Mechanical drawing; a treatise on the drawing of mechanical and machine details (1920)
Jones, Franklin Day, 1879-1967 · New York, The Industrial press; [etc., etc.] · leaf 114
and saddle it would enable one to represent theknee and saddle as they actually appeared, and also to showa sectional view of the mechanism under the saddle and insidethe knee. If, on the other hand, the view were drawn asthough the knee were actually cut through, one would notform an idea of its… … t7 {Mfrhy iwzd SECTION AT A B Machinery Fig. 3. Conventional Method of showing a Section of a Spur-gear Wheel In Fig. 3 are two views of a gear wheel. The one at theleft side is a side view, and to show the shape to which thearms are to be formed, a sectional view of one of the arms isdrawn in this…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
