ld be such that the arc joinsneatly with the lines at each end. Drawings of Parts for which Tolerances are Specified. — Inthe manufacture of machine parts, perfection is impossible, ^ MECHANICAL DRAWING although, with the machines and the precision measuringtools now available, it is practicable to… … Machinery Fig. 3. Example illustrating Methods of indicating Radial Dimensions of constructing machinery and tools is to adopt certain toler-ances or allowable errors. The various parts forming themachine are then finished to some dimension which is withinthe minimum and maximum dimensions allowed.…
