r over fifteen years. THE COMPLETE OUTFIT. The outfit for students in mechanical and machine drawingis as follows: (i) The Drawing-board for academy and freshman work isi6X2ix£, the same as that used for free-hand drawing.The material should be soft pine and constructed as shown byFig. i. (2) 1… … Fig. i. (5) Instruments. Pocket Book Set, shown by Fig. 2,recommended as a first-class medium-priced set of instruments.It contains
