mm I 3^> § 111<»•$ $ x <tj -vi Q kj … l66 MECHANICAL DRAWING. Mortise and Tenon Joggled Joint.—This joint, Fig. 230, isa modification of the preceding one to suit the angle at whichthe timbers are inclined. The left hand end of the tenon is cutsquare to the plane of the abutment to avoid the sharp end whichwould tend to shear the…
