Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)

Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 30

An illustration from Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing, 1910, leaf 30 — Right and Wrong—Quarter and Eighth Bends. … ! Fie*. 30> Showing How Curve of Trap is Made Too Low Dowsio 28 MECHANICAL DRAWING FOR PLUMBERS

Plumbing · Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
