Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 47
I … FlGi.48. Drawing Showing- Urinals in TwoDifferent Positions. scale on which plans are illustrated is toosmall to work easily. In drawing the front view of the urinal,it will be noticed, by the way, that tnefixture is in such a position that the wasteis carried directly back. In this case, wemight…
Plumbing · Mechanical drawing
