Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 81
e one following, we propose totake up the plumbing of a resi-dence, and show it in full, be-lieving as we do, that this branch ofthe work is fully as important to theplumber as any that we have taken up.For this purpose we show a full set ofplans for such a residence, Fig. 1 repre-senting the…
Plumbing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
