Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 81
of Rbsiuekce. views from the most advantageous pointof view, and before leaving the subjectof the plumbing for this residence, weshall show a single elevation of the en-tire work of the house, taken from oneview point. Now in Fig. 6 we shew anelevation of the work in the kitchen onthe first floor,…
Plumbing · Mechanical drawing
