Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 82
evation of the en-tire work of the house, taken from oneview point. Now in Fig. 6 we shew anelevation of the work in the kitchen onthe first floor, and the laundry in thecellar. These fixtures.are so located thatthey can be shown to advantage in theone view, which is obtained by viewingthe work…
Plumbing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
