also the roof, in order to show the roofconnection for this stack, and also for theone in Fig. 7 we show by a note how theyare to be run. Fig. 7 represents an elevation of thewater closet located in the cellar, and thetoilet room located on the first floor. Thestack serving the toilet room passes…
