Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 86
viewedalong the direction of arrow M in Fig. 4,which gives us a very clear view of thework. In this view the main back airline stands in front of the main stack,and we attach a note showing where theconnection of the former with the lattermay be found. In the same way weshow a note on Fig. 5… … Ftcs.W C-E.-UI-A.B. 1t?3_.-V£L OF COTTAGE HouSE< 84 MECHANICAL DRAWING FOR PLUMBERS M in Fig. 3, and as compared with. Fig.9, does not show the worK so clearly, al-though to the best advantage consideringthe relative locations of tnose fixtures.In our next article we shall show onecomplete…
Plumbing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
