Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1883)

Rose, Joshua · Philadelphia, H.C. Baird & Co.; London, S. Low, Marston, Searle & Rivington · leaf 145

An illustration from Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers, 1883, leaf 145
Fig. 190. taken not to draw them too short or too long-, as thiswould impair the appearance very much, as is shownin Figure 187. … Fig. T91. To draw the piece shown in Figure 188, the linesare drawn in tlic order indicated by the letters in Fig-ure 189, the example being given for practice. It iswell for the In^ginner to draw examples of common()l)jects, such as the liaml hammer in 1^igure 190, or thechuck plate in Figure 191,…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
