Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1883)
ius, an equal number ofpoints of division, as i, 2, 3, 4, 5. With the pom-passes set to the radius of the generating circle, thatis, A B, from B, as a centre, mark the arc I, from D,the arc J, from E, the arc K, from F, and so on, mark-ing as many arcs as there are points of division on BC. With… … Fig. 239. points of division, as a, b, c, d; and ^ will be anotherpoint on the epicycloidal curve. From point 3, setoff three divisions, and so on, and through the pointsso obtained draw by hand, or with a scroll, the curve.Hypocycloids for the Hanks of the teeth maybe tracedin a similar manner.…
Mechanical drawing
