Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments. Elementary instruction in practical mechanical drawing. Together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1889)
he eccentric is let into the strap and is provided withan eye to receive a circular nut by means of whichthe length of the eccentric rod may be adjusted, ahexagon nut being upon the other or outer end of theeye. Figure 330 shows the construction of the connect-ing rod, the brasses of which are…
