Weick, Charles William · New York : McGraw-Hill · leaf 31
IFlo. 21. … To Find the Point of Tangency of a Given Circular Arc and aGiven Straight Line (Fig. 21). Let AB be the given arc of center E; and CD, the given line.From E draw a perpendicular to CD. The intersection a will bethe point of tangency.
Mechanical drawing
