Fig. 203. ohms, and inductance of Lu of 0.05 henry, and a resistance R3, of 20 ohms.Find the impedance and electromotive force when a current of 2 amperesis sent through the circuit, and the current when e.m.f. of 120 volts isimpressed on the circuit,frequency being taken as 60. Also find the… … Fig. 204. units long. The capacity is represented by the line be, drawn downwardsfrom b and whose length is 2j7/Ci = 2X3.1416X60X0.0001 = 26>55-From the point c a horizontal line cd, 12 units long, is drawn to representR2. From the point d the line de is drawn vertically upwards to representthe…
