m C to E and from B to P. Burr Truss of Five Panels.(Fig. 129.) — Four-fifths of the loadmay be taken as concentrated at thepoints P, K, L and P, the other fifthbeing supported directly by the twoabutments. For the strains in BAand CD the truss may be considered as a queen-post truss, with the… … Fig. 128.
