The mechanical engineer's pocket-book. A reference-book of rules, tables, data, and formulæ, for the use of engineers, mechanics, and students (1910)
Kent, William, 1851-1918 · New York, J. Wiley & sons · leaf 93
33. To construct a hexagonupon a given straight line (Fig. 33). — From A and B, the ends ofthe given line, with radius A B,describe arcs cutting at g; from g,with the radius g A, describe a circle;with the same radius set off the arcsAG, G F, and B D, D <E. Join thepoints so found to form the…
Mechanical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
