the returnstroke, which may be called the back-pressure. The dottedline represents the pressure just above atmosphere, while thefull line diagram shows a pressure of 14.7 lbs. below it. The physical principle on which the condensation of steamcauses the practical vacuum is that one cubic inch of… … Fig. 68. proportion less only the volume filled by the tenuous vaporwhich even cool water gives off in a vacuum. It will only benecessary to draw off the condensed steam by proper appa-ratus to enable the vacuum to be maintained which the con-densation has created. The earliest historic…
