Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 145
Fig. 77. I08 MECHANICAL ENGINEERING OF POWER PLANTS. is concerned, but making much more complete use of theprinciple of induced currents for maintaining the vacuum, is theBulkley condenser, shown in Fig. jj. The principle of sealing … the discharge in the hot-well and locating the condenser at theheight of 34 feet above the level of the water in such well are CONDENSING AND NON-CONDENSING ENGINES. IO9 retained, but there is no pot as In the Ransom design. Fromthe section shown in Fig. 78 it will appear that the exhaust-steam…
Mechanical engineering · Steam power plants
