city, and draws in waterfrom a cold-well A (Fig. 84), and when the steam and watermeet, the steam is condensed and flows with the rapidly mov-ing water out through the discharge into the hot-well B. Thedischarge is sealed as shown in the general view, and thevelocity of flow overbalances… … 112 MECHANICAL ENGINEERING OF POWER PLANTS. controlled by the valve permits the exhaust to be carried tathe open air when for any reason it is desirable to run theengine non-condensing. It will be observed that this arrangement also, like that ia outsiolC view. 6ECTIONAI. CUTA
