ck. Rough plate is to be preferred to fluted ; itwill admit more light, while it is equally translucent. Theflutes often become filled with dust and dirt, which will accumu-late and be held in the recesses of the fluting. WEIGHT OF ROUGH GLASS PER SQUARE FOOT. Thickness. Weight. Thi ckness. Weight.… … light bar. B is the covering; A is the main supporting ba, ofwrought iron, ^ inch thick by the height to suit the span ; Care small bars riveted to side, serving as a rebate for the glass.If the main bars are long and several layers of glass are re-quired, the C bars should be made as steps…
