Fig. 172. to that caused by the cam against the first roller. This out-side cam arrangement has the advantage that the rolleralways turns in the same direction. The two-roller or yoke … Fig. 173.plan has a grave objection from the difficulty that wear pre-vents the distance between the roller or yoke surfaces remain-ing always the same as the net diameter of the cam at everypoint. If the roller or yoke does not touch the cam con-tinuously, there is a jar and shock followed by wear…
