Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 269
Fig. 195. … Fig. 196. 123. Allen Link-motion.—The link-motion first proposedby Allen is the one which in a modified form is known as the REVERSING VALVE-GEARS. LINK-MOTIONS. 233 Pius Fink gear. It has no eccentric-rod properly so called,but the link is an integral part of the back strap. Thehalf of the strap…
Mechanical engineering · Steam power plants
